# Performance measurement ## Benchmark tools TensorFlow Lite benchmark tools currently measure and calculate statistics for the following important performance metrics: * Initialization time * Inference time of warmup state * Inference time of steady state * Memory usage during initialization time * Overall memory usage The benchmark tools are available as benchmark apps for Android and iOS and as native command-line binaries, and they all share the same core performance measurement logic. Note that the available options and output formats are slightly different due to the differences in runtime environment. ### Android benchmark app There are two options of using the benchmark tool with Android. One is a [native benchmark binary](#native-benchmark-binary) and another is an Android benchmark app, a better gauge of how the model would perform in the app. Either way, the numbers from the benchmark tool will still differ slightly from when running inference with the model in the actual app. This Android benchmark app has no UI. Install and run it by using the `adb` command and retrieve results by using the `adb logcat` command. #### Download or build the app Download the nightly pre-built Android benchmark apps using the links below: * [android_aarch64](https://storage.googleapis.com/tensorflow-nightly-public/prod/tensorflow/release/lite/tools/nightly/latest/android_aarch64_benchmark_model.apk) * [android_arm](https://storage.googleapis.com/tensorflow-nightly-public/prod/tensorflow/release/lite/tools/nightly/latest/android_arm_benchmark_model.apk) As for Android benchmark apps that support [TF ops](https://www.tensorflow.org/lite/guide/ops_select) via [Flex delegate](https://github.com/tensorflow/tensorflow/tree/master/tensorflow/lite/delegates/flex), use the links below: * [android_aarch64](https://storage.googleapis.com/tensorflow-nightly-public/prod/tensorflow/release/lite/tools/nightly/latest/android_aarch64_benchmark_model_plus_flex.apk) * [android_arm](https://storage.googleapis.com/tensorflow-nightly-public/prod/tensorflow/release/lite/tools/nightly/latest/android_arm_benchmark_model_plus_flex.apk) You can also build the app from source by following these [instructions](https://github.com/tensorflow/tensorflow/tree/master/tensorflow/lite/tools/benchmark/android). Note: It is required to build the app from the source if you want to run the Android benchmark apk on x86 CPU or Hexagon delegate or if your model contains [select TF operators](../guide/ops_select) or [custom operators](../guide/ops_custom). #### Prepare benchmark Before running the benchmark app, install the app and push the model file to the device as follows: ```shell adb install -r -d -g android_aarch64_benchmark_model.apk adb push your_model.tflite /data/local/tmp ``` #### Run benchmark ```shell adb shell am start -S \ -n org.tensorflow.lite.benchmark/.BenchmarkModelActivity \ --es args '"--graph=/data/local/tmp/your_model.tflite \ --num_threads=4"' ``` `graph` is a required parameter. * `graph`: `string` \ The path to the TFLite model file. You can specify more optional parameters for running the benchmark. * `num_threads`: `int` (default=1) \ The number of threads to use for running TFLite interpreter. * `use_gpu`: `bool` (default=false) \ Use [GPU delegate](gpu). * `use_nnapi`: `bool` (default=false) \ Use [NNAPI delegate](nnapi). * `use_xnnpack`: `bool` (default=`false`) \ Use [XNNPACK delegate](https://github.com/tensorflow/tensorflow/tree/master/tensorflow/lite/delegates/xnnpack). * `use_hexagon`: `bool` (default=`false`) \ Use [Hexagon delegate](hexagon_delegate). Depending on the device you are using, some of these options may not be available or have no effect. Refer to [parameters](https://github.com/tensorflow/tensorflow/tree/master/tensorflow/lite/tools/benchmark#parameters) for more performance parameters that you could run with the benchmark app. View the results using the `logcat` command: ```shell adb logcat | grep "Inference timings" ``` The benchmark results are reported as: ``` ... tflite : Inference timings in us: Init: 5685, First inference: 18535, Warmup (avg): 14462.3, Inference (avg): 14575.2 ``` ### Native benchmark binary Benchmark tool is also provided as a native binary `benchmark_model`. You can execute this tool from a shell command line on Linux, Mac, embedded devices and Android devices. #### Download or build the binary Download the nightly pre-built native command-line binaries by following the links below: * [linux_x86-64](https://storage.googleapis.com/tensorflow-nightly-public/prod/tensorflow/release/lite/tools/nightly/latest/linux_x86-64_benchmark_model) * [linux_aarch64](https://storage.googleapis.com/tensorflow-nightly-public/prod/tensorflow/release/lite/tools/nightly/latest/linux_aarch64_benchmark_model) * [linux_arm](https://storage.googleapis.com/tensorflow-nightly-public/prod/tensorflow/release/lite/tools/nightly/latest/linux_arm_benchmark_model) * [android_aarch64](https://storage.googleapis.com/tensorflow-nightly-public/prod/tensorflow/release/lite/tools/nightly/latest/android_aarch64_benchmark_model) * [android_arm](https://storage.googleapis.com/tensorflow-nightly-public/prod/tensorflow/release/lite/tools/nightly/latest/android_arm_benchmark_model) As for nightly pre-built binaries that support [TF ops](https://www.tensorflow.org/lite/guide/ops_select) via [Flex delegate](https://github.com/tensorflow/tensorflow/tree/master/tensorflow/lite/delegates/flex), use the links below: * [linux_x86-64](https://storage.googleapis.com/tensorflow-nightly-public/prod/tensorflow/release/lite/tools/nightly/latest/linux_x86-64_benchmark_model_plus_flex) * [linux_aarch64](https://storage.googleapis.com/tensorflow-nightly-public/prod/tensorflow/release/lite/tools/nightly/latest/linux_aarch64_benchmark_model_plus_flex) * [linux_arm](https://storage.googleapis.com/tensorflow-nightly-public/prod/tensorflow/release/lite/tools/nightly/latest/linux_arm_benchmark_model_plus_flex) * [android_aarch64](https://storage.googleapis.com/tensorflow-nightly-public/prod/tensorflow/release/lite/tools/nightly/latest/android_aarch64_benchmark_model_plus_flex) * [android_arm](https://storage.googleapis.com/tensorflow-nightly-public/prod/tensorflow/release/lite/tools/nightly/latest/android_arm_benchmark_model_plus_flex) To benchmark with [TensorFlow Lite Hexagon delegate](https://www.tensorflow.org/lite/android/delegates/hexagon), we have also pre-built the required `libhexagon_interface.so` files (see [here](https://github.com/tensorflow/tensorflow/blob/master/tensorflow/lite/delegates/hexagon/README.md) for details about this file). After downloading the file of the corresponding platform from the links below, please rename the file to `libhexagon_interface.so`. * [android_aarch64](https://storage.googleapis.com/tensorflow-nightly-public/prod/tensorflow/release/lite/tools/nightly/latest/android_aarch64_libhexagon_interface.so) * [android_arm](https://storage.googleapis.com/tensorflow-nightly-public/prod/tensorflow/release/lite/tools/nightly/latest/android_arm_libhexagon_interface.so) You can also build the native benchmark binary from [source](https://github.com/tensorflow/tensorflow/tree/master/tensorflow/lite/tools/benchmark) on your computer. ```shell bazel build -c opt //tensorflow/lite/tools/benchmark:benchmark_model ``` To build with Android NDK toolchain, you need to set up the build environment first by following this [guide](../android/lite_build#set_up_build_environment_without_docker), or use the docker image as described in this [guide](../android/lite_build#set_up_build_environment_using_docker). ```shell bazel build -c opt --config=android_arm64 \ //tensorflow/lite/tools/benchmark:benchmark_model ``` Note: It is a valid approach to push and execute binaries directly on an Android device for benchmarking, but it can result in subtle (but observable) differences in performance relative to execution within an actual Android app. In particular, Android's scheduler tailors behavior based on thread and process priorities, which differ between a foreground Activity/Application and a regular background binary executed via `adb shell ...`. This tailored behavior is most evident when enabling multi-threaded CPU execution with TensorFlow Lite. Therefore, the Android benchmark app is preferred for performance measurement. #### Run benchmark To run benchmarks on your computer, execute the binary from the shell. ```shell path/to/downloaded_or_built/benchmark_model \ --graph=your_model.tflite \ --num_threads=4 ``` You can use the same set of [parameters](https://github.com/tensorflow/tensorflow/tree/master/tensorflow/lite/tools/benchmark#parameters) as mentioned above with the native command-line binary. #### Profiling model ops The benchmark model binary also allows you to profile model ops and get the execution times of each operator. To do this, pass the flag `--enable_op_profiling=true` to `benchmark_model` during invocation. Details are explained [here](https://github.com/tensorflow/tensorflow/tree/master/tensorflow/lite/tools/benchmark#profiling-model-operators). ### Native benchmark binary for multiple performance options in a single run A convenient and simple C++ binary is also provided to [benchmark multiple performance options](https://github.com/tensorflow/tensorflow/tree/master/tensorflow/lite/tools/benchmark#benchmark-multiple-performance-options-in-a-single-run) in a single run. This binary is built based on the aforementioned benchmark tool that could only benchmark a single performance option at a time. They share the same build/install/run process, but the BUILD target name of this binary is `benchmark_model_performance_options` and it takes some additional parameters. An important parameter for this binary is: `perf_options_list`: `string` (default='all') \ A comma-separated list of TFLite performance options to benchmark. You can get nightly pre-built binaries for this tool as listed below: * [linux_x86-64](https://storage.googleapis.com/tensorflow-nightly-public/prod/tensorflow/release/lite/tools/nightly/latest/linux_x86-64_benchmark_model_performance_options) * [linux_aarch64](https://storage.googleapis.com/tensorflow-nightly-public/prod/tensorflow/release/lite/tools/nightly/latest/linux_aarch64_benchmark_model_performance_options) * [linux_arm](https://storage.googleapis.com/tensorflow-nightly-public/prod/tensorflow/release/lite/tools/nightly/latest/linux_arm_benchmark_model_performance_options) * [android_aarch64](https://storage.googleapis.com/tensorflow-nightly-public/prod/tensorflow/release/lite/tools/nightly/latest/android_aarch64_benchmark_model_performance_options) * [android_arm](https://storage.googleapis.com/tensorflow-nightly-public/prod/tensorflow/release/lite/tools/nightly/latest/android_arm_benchmark_model_performance_options) ### iOS benchmark app To run benchmarks on iOS device, you need to build the app from [source](https://github.com/tensorflow/tensorflow/tree/master/tensorflow/lite/tools/benchmark/ios). Put the TensorFlow Lite model file in the [benchmark_data](https://github.com/tensorflow/tensorflow/tree/master/tensorflow/lite/tools/benchmark/ios/TFLiteBenchmark/TFLiteBenchmark/benchmark_data) directory of the source tree and modify the `benchmark_params.json` file. Those files are packaged into the app and the app reads data from the directory. Visit the [iOS benchmark app](https://github.com/tensorflow/tensorflow/tree/master/tensorflow/lite/tools/benchmark/ios) for detailed instructions. ## Performance benchmarks for well known models This section lists TensorFlow Lite performance benchmarks when running well known models on some Android and iOS devices. ### Android performance benchmarks These performance benchmark numbers were generated with the [native benchmark binary](https://github.com/tensorflow/tensorflow/tree/master/tensorflow/lite/tools/benchmark). For Android benchmarks, the CPU affinity is set to use big cores on the device to reduce variance (see [details](https://github.com/tensorflow/tensorflow/tree/master/tensorflow/lite/tools/benchmark#reducing-variance-between-runs-on-android)). It assumes that models were downloaded and unzipped to the `/data/local/tmp/tflite_models` directory. The benchmark binary is built using [these instructions](https://github.com/tensorflow/tensorflow/tree/master/tensorflow/lite/tools/benchmark#on-android) and assumed to be in the `/data/local/tmp` directory. To run the benchmark: ```sh adb shell /data/local/tmp/benchmark_model \ --num_threads=4 \ --graph=/data/local/tmp/tflite_models/${GRAPH} \ --warmup_runs=1 \ --num_runs=50 ``` To run with nnapi delegate, set `--use_nnapi=true`. To run with GPU delegate, set `--use_gpu=true`. The performance values below are measured on Android 10.
Model Name Device CPU, 4 threads GPU NNAPI
Mobilenet_1.0_224(float) Pixel 3 23.9 ms 6.45 ms 13.8 ms
Pixel 4 14.0 ms 9.0 ms 14.8 ms
Mobilenet_1.0_224 (quant) Pixel 3 13.4 ms --- 6.0 ms
Pixel 4 5.0 ms --- 3.2 ms
NASNet mobile Pixel 3 56 ms --- 102 ms
Pixel 4 34.5 ms --- 99.0 ms
SqueezeNet Pixel 3 35.8 ms 9.5 ms 18.5 ms
Pixel 4 23.9 ms 11.1 ms 19.0 ms
Inception_ResNet_V2 Pixel 3 422 ms 99.8 ms 201 ms
Pixel 4 272.6 ms 87.2 ms 171.1 ms
Inception_V4 Pixel 3 486 ms 93 ms 292 ms
Pixel 4 324.1 ms 97.6 ms 186.9 ms
### iOS performance benchmarks These performance benchmark numbers were generated with the [iOS benchmark app](https://github.com/tensorflow/tensorflow/tree/master/tensorflow/lite/tools/benchmark/ios). To run iOS benchmarks, the benchmark app was modified to include the appropriate model and `benchmark_params.json` was modified to set `num_threads` to 2. To use the GPU delegate, `"use_gpu" : "1"` and `"gpu_wait_type" : "aggressive"` options were also added to `benchmark_params.json`.
Model Name Device CPU, 2 threads GPU
Mobilenet_1.0_224(float) iPhone XS 14.8 ms 3.4 ms
Mobilenet_1.0_224 (quant) iPhone XS 11 ms ---
NASNet mobile iPhone XS 30.4 ms ---
SqueezeNet iPhone XS 21.1 ms 15.5 ms
Inception_ResNet_V2 iPhone XS 261.1 ms 45.7 ms
Inception_V4 iPhone XS 309 ms 54.4 ms
## Trace TensorFlow Lite internals ### Trace TensorFlow Lite internals in Android Note: This feature is available from Tensorflow Lite v2.4. Internal events from the TensorFlow Lite interpreter of an Android app can be captured by [Android tracing tools](https://developer.android.com/topic/performance/tracing). They are the same events with Android [Trace](https://developer.android.com/reference/android/os/Trace) API, so the captured events from Java/Kotlin code are seen together with TensorFlow Lite internal events. Some examples of events are: * Operator invocation * Graph modification by delegate * Tensor allocation Among different options for capturing traces, this guide covers the Android Studio CPU Profiler and the System Tracing app. Refer to [Perfetto command-line tool](https://developer.android.com/studio/command-line/perfetto) or [Systrace command-line tool](https://developer.android.com/topic/performance/tracing/command-line) for other options. #### Adding trace events in Java code This is a code snippet from the [Image Classification](https://github.com/tensorflow/examples/tree/master/lite/examples/image_classification/android) example app. TensorFlow Lite interpreter runs in the `recognizeImage/runInference` section. This step is optional but it is useful to help notice where the inference call is made. ```java Trace.beginSection("recognizeImage"); ... // Runs the inference call. Trace.beginSection("runInference"); tflite.run(inputImageBuffer.getBuffer(), outputProbabilityBuffer.getBuffer().rewind()); Trace.endSection(); ... Trace.endSection(); ``` #### Enable TensorFlow Lite tracing To enable TensorFlow Lite tracing, set the Android system property `debug.tflite.trace` to 1 before starting the Android app. ```shell adb shell setprop debug.tflite.trace 1 ``` If this property has been set when TensorFlow Lite interpreter is initialized, key events (e.g., operator invocation) from the interpreter will be traced. After you captured all the traces, disable tracing by setting the property value to 0. ```shell adb shell setprop debug.tflite.trace 0 ``` #### Android Studio CPU Profiler Capture traces with the [Android Studio CPU Profiler](https://developer.android.com/studio/profile/cpu-profiler) by following the steps below: 1. Select **Run > Profile 'app'** from the top menus. 2. Click anywhere in CPU timeline when the Profiler window appears. 3. Select 'Trace System Calls' among CPU Profiling modes. ![Select 'Trace System Calls'](images/as_select_profiling_mode.png) 4. Press 'Record' button. 5. Press 'Stop' button. 6. Investigate the trace result. ![Android Studio trace](images/as_traces.png) In this example, you can see the hierarchy of events in a thread and statistics for each operator time and also see the data flow of the whole app among threads. #### System Tracing app Capture traces without Android Studio by following the steps detailed in [System Tracing app](https://developer.android.com/topic/performance/tracing/on-device). In this example, the same TFLite events were captured and saved to the Perfetto or Systrace format depending on the version of Android device. The captured trace files can be opened in the [Perfetto UI](https://ui.perfetto.dev/#!/). ![Perfetto trace](images/perfetto_traces.png) ### Trace TensorFlow Lite internals in iOS Note: This feature is available from Tensorflow Lite v2.5. Internal events from the TensorFlow Lite interpreter of an iOS app can be captured by [Instruments](https://developer.apple.com/library/archive/documentation/ToolsLanguages/Conceptual/Xcode_Overview/MeasuringPerformance.html#//apple_ref/doc/uid/TP40010215-CH60-SW1) tool included with Xcode. They are the iOS [signpost](https://developer.apple.com/documentation/os/logging/recording_performance_data) events, so the captured events from Swift/Objective-C code are seen together with TensorFlow Lite internal events. Some examples of events are: * Operator invocation * Graph modification by delegate * Tensor allocation #### Enable TensorFlow Lite tracing Set the environment variable `debug.tflite.trace` by following the steps below: 1. Select **Product > Scheme > Edit Scheme...** from the top menus of Xcode. 2. Click 'Profile' in the left pane. 3. Deselect 'Use the Run action's arguments and environment variables' checkbox. 4. Add `debug.tflite.trace` under 'Environment Variables' section. ![Set environment variable](images/xcode_profile_environment.png) If you want to exclude TensorFlow Lite events when profiling the iOS app, disable tracing by removing the environment variable. #### XCode Instruments Capture traces by following the steps below: 1. Select **Product > Profile** from the top menus of Xcode. 2. Click **Logging** among profiling templates when Instruments tool launches. 3. Press 'Start' button. 4. Press 'Stop' button. 5. Click 'os_signpost' to expand OS Logging subsystem items. 6. Click 'org.tensorflow.lite' OS Logging subsystem. 7. Investigate the trace result. ![Xcode Instruments trace](images/xcode_traces.png) In this example, you can see the hierarchy of events and statistics for each operator time. ### Using the tracing data The tracing data allows you to identify performance bottlenecks. Here are some examples of insights that you can get from the profiler and potential solutions to improve performance: * If the number of available CPU cores is smaller than the number of inference threads, then the CPU scheduling overhead can lead to subpar performance. You can reschedule other CPU intensive tasks in your application to avoid overlapping with your model inference or tweak the number of interpreter threads. * If the operators are not fully delegated, then some parts of the model graph are executed on the CPU rather than the expected hardware accelerator. You can substitute the unsupported operators with similar supported operators.
